THE IMPORTANCE OF THERMAL DESIGN FOR PCB

Time of issue: 2022-05-05

During the operation of electronic equipment, in addition to useful work, most of the electric energy consumed is converted into thermal energy. The heat generated by electronic equipment makes the internal temperature rise rapidly. If the heat is not dissipated in time, the electronic equipment will continue be heating up, the components will fail due to overheating, and the reliability of electronic equipment will decline.

SMT increases the installation density of electronic equipment, reduces the effective cooling area, and seriously affects the reliability of equipment temperature rise. Therefore, it is very important to study the thermal design.
